Philips MSD Platinum 16R Stage & Touring Lamp – 330W, 16,000 lm, 8000K, Dimmable - 293050
28 In Stock! Same Day Shipping Through 3PM CST! Need more? Call today @ 888.391.5596- Important Specs
- 16000 Lumens
- 1500 Hours
- 330 Watts
Philips MSD Platinum 16R Stage & Touring Lamp (293050) – 330W, 16,000 lm, 8000K, Dimmable
Touring-grade Platinum 16R performance—up to 16,000 lumens at 8000K with universal positioning and dimmable control for pro fixtures.
High-Intensity Output
Up to 16,000 lumens for powerful beams and strong throw in professional moving head fixtures.
Up to 16,000 lumens for powerful beams and strong throw in professional moving head fixtures.
Crisp, Cool White Light
8000K color temperature for clean, punchy looks on stage and in venues.
8000K color temperature for clean, punchy looks on stage and in venues.
Compact Arc for Sharp Projection
1.3mm arc length supports crisp projection and clean optical performance.
1.3mm arc length supports crisp projection and clean optical performance.
Longer Service Life
1,500 hours (life to 50% failures) helps reduce relamping frequency and downtime.
1,500 hours (life to 50% failures) helps reduce relamping frequency and downtime.
Flexible Operation
Universal operating position plus dimmable performance for modern touring rigs and programming.
Universal operating position plus dimmable performance for modern touring rigs and programming.
| Specifications | |
|---|---|
| Lamp Type | MSD Platinum (short-arc discharge) |
| Model / Part Number | MSD Platinum 16R / 293050 |
| Power Consumption | 330 W |
| Luminous Flux | 16,000 lm (nom) / 14,300 lm (min) |
| Correlated Color Temperature (CCT) | 8000 K (nom) |
| Chromaticity (x, y) | x = 299 (nom), y = 303 (nom) |
| Arc Length | 1.3 mm (nom) |
| Operating Position | Universal (Any / U) |
| Life to 50% Failures | 1,500 hour(s) (nom) |
| Dimmable | Yes |
| Net Weight | 0.080 kg |
| CE Mark | Yes |
| Order Code | 928195205314 |
| Full Product Code | 871829170438600 |
| Order Product Name | MSD Platinum 16 R 1CT/8 |
| Cap-Base | - |
Works With / Compatible Fixtures
This bulb works in many applications including the following:
- Acme XP-16R
- Acme XP-16R BSW
- Acme XP-16R BSW PRO
- Acme XP-16R Beam
- Acme XP-16R Beam II
- American DJ Visi Hybrid 16RX
- Clay Paky Sharpy Wash 330
- DTS MAX
- DTS MAX L
- Elation Professional Platinum Wash 16R Pro
- Fine Art Fine 330 Spot
- Fine Art Fine 330 Wash
- GTD GTD-330 N BSW
- Jolly X-Super Beam
- Terbly PT330W
What's in the Box
- Philips MSD Platinum 16R Stage & Touring Lamp (293050)
- Protective packaging
- Product documentation (as included by manufacturer)
Why Choose the Philips MSD Platinum 16R?
- Up to 16,000 lumens of high-intensity output for powerful beams and long throw.
- 8000K color temperature for clean, crisp looks in touring and venue applications.
- 1.3mm arc length supports sharp projection and clean optics performance.
- Universal operating position plus dimmable performance for flexible programming.
- 1,500-hour life to 50% failures helps reduce downtime and maintenance.
